VPN L2TP
FortiGate-1000 Administration Guide 01-28006-0009-20041105 265
5 Select Port Forwarding.
6 Set the External IP Address to 0.0.0.0.
The 0.0.0.0 External IP Address matches any IP address. Alternatively, if PPTP users
always connect to the same IP address, you can specify that IP address.
7 Set the External Service Port to 1723.
8 Set the Map to IP address to 192.168.23.1.
9 Set Map to Port to 1723.
10 Set Protocol to TCP.
11 Select OK.
To configure the firewall policy
1 Go to Firewall > Policy.
2 Select Create New.
3 For Interface/Zone:
• Set Source to external
• Set Destination to internal
4 For Address name:
• Set Source to All
• Set Destination to PPTP_pass
5 Set Schedule as required.
6 Set Service to ANY.
7 Set action to ACCEPT.
8 Select NAT.
9 Select OK.
L2TP
You can set up VPN connections between FortiGate units and remote Windows
clients using Layer 2 Tunneling Protocol (L2TP). L2TP lets you create a secure
connection between a client computer running Microsoft Windows and your internal
network behind a FortiGate unit.
L2TP combines the features of two other tunneling protocols: PPTP from Microsoft
and L2F from Cisco Systems. L2TP is supported by most recent versions of Windows.
Some implementations of L2TP support elements of IPSec. These elements must be
disabled when L2TP is used with FortiGate units.
Note: L2TP VPNs are only supported in NAT/Route mode.
