Foscam FI8905W - 2 Surveillance Software GUI

W
W
w
w
ww.foscam.
ww.foscam.
us
us
Foscam Digital Technologies LLC
Telephone: 1-800-930-0949
6
Figure 1.1
1 WIFI Antenna: Wireless Antenna
2 LENS: CMOS sensor with fixed focus lens
3 Infrared LED: 60 IR LEDs
Back View
Figure 1.2
LAN: RJ-45/10-100 Base T
RJ45 Port
DC 5V Power
Reset
2
1
3
