Foscam FI9961EP - Surveillance Window

18
3.2 Surveillance Window
Section 1 Live Video / Settings Buttons / Playback
: Path to surveillance window. Click this button and back to the surveillance window
: Path to Administrator Control Panel. Click it, and it will lead to Administrator Control Panel and
do advanced settings.
: Path to playback window, click it to search / playback the records.
Section 2 Multi-Device Window
The firmware inside the camera supports up to maximum of 9 cameras being monitoring at the same time. You
can add other cameras in multi-camera panel.
Section 3 Mode / Stream / WDR / NAA / Mirror / Flip Buttons / Zoom in / out
Mode
1) 50Hz ---------Indoor surveillance (Region: Europe, China)
2) 60Hz ---------Indoor surveillance (Region: USA, Canada)
3) Outdoor Mode------Outdoor surveillance
Stream
The default stream supports multiple modes, For example: HD Mode / 1080P / 25fps / 4M meanings: Stream
2
5
3
4
6
7
1
