CHAPTER
Advanced
operation
m
Connections
between
the
XR-7
and
master
recorder
and
effect
unit
•
Connect
the
six
MIDI
sound
sources
to
[INPUT]
jacks
1-6.
•
Connect
the
[MON
OUT
L],
[R]
jacks
to
the
master
recorder's
[INPUT]
jacks,
•
Connect
the
effect
unit
to
the
XR-7's
[AUX
SEND
1)
and
[AUX
RTN
1]
jacks.
[INPUT
SEL]
switch
settings
•
Set
the
channel
1-4
[INPUT
SEL]
switches
to
"INPUT."
[31
[MON
SEL]
switch
settings
•
Set
the
switch
to
"ST+FB."
[4]
[REC
SELECT]
switch
settings
•
Set
all
the
switches
to
"OFF,"
Adjusting
the
input
signal
•
Raise
the
[MASTER]
faders
to
about
7
or
8.
•
While
manually
playing
the
MIDI
sound
sources
A-F,
gradually
raise
the
channel
1-6
[INPUT]
faders
to
adjust
the
overall
balance,
and
check
the
recording
level
on
the
meters,
[^
[PAN]
knob
settings
•
Use
the
channel
1
-6
[PAN]
knobs
to
adjust
the
stereo
position
of
each
MIDI
sound
source.
[tI
Equalizer
settings
•
Use
(he
channel
1
-6
equal
izers
toadjust
the
tone
of
sound
sources
A-F.
(Set
the
[EQ
SEL]
switches
to
"INPUT
5"
and
"INPUT
6.")
[si
[FB]
knob
settings
•
Gradually
rotate
the
channel
1—3
[FB]
knobs
in
the
'TRACK"
direction
to
adjust
the
signals
from
tracks
1-3.
•
Set
the
track
4
[FB]
knob
to
"0"
(center
position).
[^
AUX
settings
•
Processing
the
signals
of
sound
sources
A-F
with
effects:
Set
the
channel
1-3
[AUX
SEL]
switches
to
"CH."
•
Processing
the
tape
playback
signal:
(Post
Foldback
Send
function)
Set
the
channel
1
-3
[AUX
SEL]
switches
to
"FB."
•
Gradually
rotate
the
channel
[AUX]
send
knobs
toward
"AUX
1",
and
adjust
the
entire
level
using
the
[AUX
SEND
1]
master
knob.
-
•
Use
the
[AUX
RTN
1]
knob
to
adjust
the
input
level
from
the
effect
unit.
ItQ
Rehearsal
•
Press
the
[PLAY]
button
to
play
back
the
XR-7,
and
start
the
MIDI
device.
•
Use
the
[FB]
knobs
to
adjust
the
signal
of
tracks
1-3,
and
use
the
[INPUT]
faders
to
adjust
the
volume
balance
of
the
MIDI
sound
sources.
•
Adjust
the
amount
of
effect,
if
necessary.
•
After
finishing
rehearsal,
rewind
the
tape
to
the
beginning.
[iTj
Mixdown
the
tape
sync
playback
•
First
start
recording
on
the
master
recorder.
•
Play
back
the
XR-7
and
start
the
MIDI
device.
•
Use
the
(MASTER]
fader
to
control
the
overall
volume,
and
to
fade-in
or
fade-out,
if
necessary.
36
