Ceiling cassette
Fan
Coil Unit
, 4
-
pipe system
Model: FP-
KM
FP-85-102-136KM4
MOUNTING BRACKETS
FRESH AIR DUCT
FAN BLOWER
MOTOR
PANEL COVER
FRESH AIR DUCT
TERMINAL BLOCK
WATER PURGE
HOT WATER OUTLET
HOT WATER INLET
CHILLED WATER INLET
AIR VENT
CHILLED WATER OUTLET
DRAINAGE
