523 7.45 461 2.34 1.98 12.5 12.4 2.65 2.07 13.9 13.1 2.77 1.98 14.4 13.4 3.34 2.07 15.8 14.1
617 10.1 561 2.7 2.19 13.6 12.7 3.12 2.34 14.8 13.3 3.27 2.25 15.2 13.6 3.95 2.36 16.6 14.3
5.0
725 13.4 681 3.15 2.47 14.4 12.9 3.66 2.65 15.6 13.5 2.84 2.54 16.0 13.8 4.64 2.66 17.4 14.5
444 5.7 462 1.93 1.67 14.4 13.4 2.22 1.83 15.3 14.1 2.35 1.77 15.7 14.4 2.85 1.84 17.2 15.2
520 7.6 560 2.2 1.92 15 13.7 2.6 2.08 16.1 14.3 2.75 1.99 16.5 14.6 3.35 2.08 18 15.4
7.0
606 9.7 682 2.54 2.2 15.5 13.9 3.02 2.35 16.8 14.5 3.21 2.26 17.2 14.8 3.93 2.33 18.8 15.6
312 2.93 463 1.25 1.22 17.2 15 1.57 1.53 17.2 15.6 1.65 1.55 17.1 16 2.03 1.65 18.4 17
357 3.74 562 1.36 1.32 18 15.3 1.8 1.76 17.7 15.8 1.89 1.76 17.7 16.2 2.35 1.84 19.2 17.2
9.0
408 4.76 682 1.52 1.49 18.5 15.5 2.05 1.99 18.3 16 2.16 1.99 18.3 16.4 2.71 2.07 19.9 17.4
259 2.1 462 1.16 1.14 17.7 15.2 1.34 1.31 18.5 16.1 1.37 1.30 18.6 16.6 1.75 1.36 20.2 17.6
295 2.65 563 1.2 1.17 18.8 15.6 1.52 1.48 19.1 16.3 1.56 1.47 19.2 16.8 2.0 1.53 20.8 17.8
11.0
330 3.26 682 1.26 1.23 19.6 15.9 1.72 1.67 19.7 16.5 1.75 1.66 19.7 17 2.28 1.72 21.4 18
206 1.39 461 0.81 0.79 19.9 16 1.07 1.05 20.2 16.7 1.09 1.05 20.2 17.2 1.3 1.19 21.2 18.5
230 1.7 563 0.82 0.80 20.7 16.3 1.19 1.16 20.8 16.9 1.22 1.183 20.7 17.4 1.48 1.35 21.8 18.7
13.0
253 2.02 683 0.87 0.84 21.3 16.5 1.31 1.27 21.4 17.1 1.34 1.29 21.3 17.6 1.64 1.52 22.3 18.9
Pf: total cooling capacity Tal: in flow air temperature dpw: pressure drop standard coil
Twi: in flow fluid temperature Qw: fluid flow rate in heat exchanger Qa: air flow
Pfs: sensible cooling capacity Tad: discharge air dry temperature Taw: discharge air wet temperature
Note
: For cooling condition: temperature different between incoming/outgoing water is 5 degree Celsius.
Design and specification are subject to change without prior notice for product Improvement.
COOLING CAPACITY TABLE
FP-80KM4
TAI DB25℃-WB17.8℃ TAI DB27℃-WB19℃ TAI DB27℃-WB19.5℃ TAI DB29℃-WB21.1℃
Twi
［℃］
612 9.88 516 2.7 2.05 13.4 12.2 3.17 2.19 14.5 12.6 3.24 2.13 14.9 13.1 3.81 2.26 16.1 13.9
718 13.2 624 3.16 2.33 14.1 12.4 3.68 2.49 15.3 12.9 3.8 2.4 15.7 13.3 4.49 2.53 17 14.1
5.0
840 17.5 751 3.66 2.61 14.8 12.6 4.28 2.78 16.1 13.1 4.43 2.67 16.5 13.5 5.25 2.83 17.8 14.3
514 7.21 516 2.2 1.81 14.7 13.3 2.63 1.95 15.9 13.8 2.72 1.87 16.3 14.2 3.28 1.98 17.6 15
599 9.5 624 2.52 2.06 15.2 13.5 3.06 2.2 16.6 14 3.17 2.11 17 14.4 3.84 2.23 18.4 15.2
7.0
693 12.4 750 2.93 2.32 15.9 13.7 3.53 2.46 17.3 14.2 3.67 2.35 17.7 14.6 4.47 2.47 19.2 15.4
366 3.92 517 1.44 1.41 16.9 14.9 1.85 1.72 17.1 15.4 1.94 1.64 17.6 15.8 2.46 1.72 19.2 16.7
421 5.04 626 1.63 1.58 17.5 15.1 2.12 1.96 17.7 15.6 2.23 1.85 18.2 16 2.8 1.94 19.7 16.9
9.0
478 6.33 752 1.82 1.77 18 15.3 2.4 2.19 18.3 15.8 2.53 2.1 18.7 16.2 3.21 2.15 20.4 17.1
270 2.27 517 1.05 1.02 19.1 15.7 1.4 1.37 19.1 16.3 1.43 1.38 19 16.8 1.73 1.53 20.1 18
302 2.77 624 1.16 1.13 19.6 15.9 1.57 1.52 19.7 16.5 1.6 1.56 19.5 17 1.96 1.72 20.7 18.2
11.0
350 3.6 750 1.245 1.2 20.2 16.1 1.74 1.7 20.2 16.7 1.85 1.80 19.8 17.1 2.28 1.92 21.3 18.3
212 1.46 518 0.605 0.582 21.6 16.6 1.1 1.07 20.8 16.9 1.12 1.09 20.7 17.4 1.35 1.31 21.4 18.7
233 1.73 626 0.675 0.644 21.9 16.7 1.2 1.16 21.4 17.1 1.23 1.19 21.3 17.6 1.5 1.45 22 18.9
13.0
250 1.96 751 0.74 0.7 22.2 16.8 1.29 1.25 22 17.3 1.32 1.27 21.9 17.8 1.64 1.59 22.6 19.1
Pf: total cooling capacity Tal: in flow air temperature dpw: pressure drop standard coil
Twi: in flow fluid temperature Qw: fluid flow rate in heat exchanger Qa: air flow
Pfs: sensible cooling capacity Tad: discharge air dry temperature Taw: discharge air wet temperature
Note
: For cooling condition: temperature different between incoming/outgoing water is 5 degree Celsius.
Design and specification are subject to change without prior notice for product Improvement.
