COOLING CAPACITY TABLE
FP-85KM4
TAI DB25℃-WB17.8℃ TAI DB27℃-WB19℃ TAI DB27℃-WB19.5℃ TAI DB29℃-WB21.1℃
Twi
［℃］
604 10.4 501 2.71 2.24 12 12 3.1 2.48 12.6 12.6 3.2 2.4 13.0 13.0 3.85 2.63 13.6 13.6
750 15.4 651 3.35 2.81 12.4 12.3 3.84 3.02 13.4 12.9 3.98 2.96 13.7 13.3 4.82 3.12 14.9 13.9
5.0
950 23.5 850 4.23 3.35 13.5 12.5 4.86 3.62 14.5 13.1 5.03 3.5 14.9 13.5 6.12 3.68 16.2 14.1
534 8.3 500 2.36 2.06 13 12.8 2.73 2.25 13.8 13.4 2.83 2.18 14.2 13.8 3.47 2.33 15.3 14.4
673 12.6 652 2.95 2.47 13.9 13 3.42 2.7 14.8 13.6 3.56 2.59 15.3 14 4.38 2.75 16.5 14.6
7.0
846 19.0 850 3.7 2.95 14.8 13.2 4.32 3.2 15.9 13.8 4.48 3.08 16.3 14.2 5.56 3.24 17.7 14.8
448 7.5 502 1.91 1.79 14.5 13.8 2.27 1.97 15.4 14.4 2.37 1.89 15.9 14.8 2.8 2.08 16.7 15.8
544 10.7 650 2.36 2.12 15.4 14 2.83 2.34 16.4 14.6 2.88 2.26 16.7 15.1 3.5 2.45 17.8 16
9.0
680 12.8 850 2.93 2.54 16.2 14.2 3.53 2.78 17.3 14.8 3.6 2.69 17.6 15.3 4.41 2.88 18.9 16.2
329 4.33 502 1.35 1.32 17.2 15 1.7 1.66 17.2 15.6 1.74 1.63 17.4 16.1 2.15 1.77 18.5 17.1
400 6.18 650 1.64 1.61 17.7 15.2 2.08 2.01 17.8 15.8 2.12 1.94 18.1 16.3 2.65 2.09 19.4 17.3
11.0
493 9.0 851 1.98 1.92 18.3 15.4 2.56 2.4 18.6 16 2.61 2.31 18.9 16.5 3.29 2.5 20.2 17.5
244 2.53 502 0.93 0.91 19.6 15.9 1.26 1.22 19.7 16.5 1.29 1.26 19.5 17.0 1.52 1.49 20.1 18.3
291 3.47 651 1.08 1.05 20.2 16.1 1.51 1.48 20.2 16.7 1.54 1.5 20.1 17.2 1.84 1.8 20.7 18.5
13.0
348 4.79 850 1.25 1.19 20.8 16.3 1.81 1.76 20.8 16.9 1.84 1.78 20.7 17.4 2.22 2.15 21.4 18.7
Pf: total cooling capacity Tal: in flow air temperature dpw: pressure drop standard coil
Twi: in flow fluid temperature Qw: fluid flow rate in heat exchanger Qa: air flow
Pfs: sensible cooling capacity Tad: discharge air dry temperature Taw: discharge air wet temperature
Note
: For cooling condition: temperature different between incoming/outgoing water is 5 degree Celsius.
Design and specification are subject to change without prior notice for product Improvement.
COOLING CAPACITY TABLE
FP-102KM4
TAI DB25℃-WB17.8℃ TAI DB27℃-WB19℃ TAI DB27℃-WB19.5℃ TAI DB29℃-WB21.1℃
Twi
［℃］
702 13.6 600 3.15 2.64 12.2 12.2 3.55 2.9 12.9 12.9 3.72 2.81 13.3 13.2 4.46 2.97 14.5 13.9
886 20.6 780 3.95 3.18 13.1 12.4 4.47 3.44 14.1 13.1 4.69 3.322 14.5 13.4 5.63 3.52 15.7 14.1
5.0
1122 31.6 1020 4.98 3.76 14.2 12.6 5.65 4.06 15.3 13.3 5.94 3.95 15.6 13.6 7.16 4.14 17 14.3
620 10.8 600 2.78 2.32 13.7 12.9 3.16 2.55 14.5 13.6 3.28 2.47 14.9 14.0 3.89 2.67 15.9 14.9
778 16.3 781 3.46 2.76 14.6 13.1 3.97 3.02 15.6 13.8 4.12 2.94 15.9 14.2 4.89 3.16 17 15.1
7.0
980 24.7 1021 4.34 3.29 15.5 13.3 5.0 3.6 16.6 14 5.19 3.45 17 14.4 6.19 3.71 18.2 15.3
502 9.29 600 2.19 2.03 15.1 14 2.56 2.22 16.1 14.7 2.66 2.15 16.4 15.1 3.24 2.31 17.6 16
625 13.8 781 2.69 2.41 15.9 14.2 3.17 2.66 16.9 14.9 3.31 2.56 17.3 15.3 4.05 2.75 18.5 16.2
9.0
780 16.3 1022 3.33 2.87 16.7 14.4 3.95 3.16 17.8 15.1 4.13 3.02 18.2 15.5 5.09 3.21 19.6 16.4
393 5.97 601 1.63 1.59 17.2 15.0 1.98 1.92 17.5 15.7 2.08 1.84 17.9 16.1 2.51 2.03 18.9 17.2
481 8.61 781 1.96 1.92 17.7 15.2 2.42 2.28 18.3 15.9 2.55 2.18 18.7 16.3 3.1 2.4 19.8 17.4
11.0
591 12.5 1021 2.37 2.3 18.3 15.4 2.97 2.74 19 16.1 3.13 2.6 19.4 16.5 3.85 2.84 20.7 17.6
280 3.23 600 1.11 1.09 19.6 15.9 1.46 1.43 19.9 16.6 1.48 1.44 19.8 17.1 1.83 1.71 20.5 18.3
334 4.46 781 1.3 1.26 20.2 16.1 1.74 1.7 20.5 16.8 1.77 1.72 20.4 17.3 2.21 2.03 21.2 18.5
13.0
399 6.12 1023 1.5 1.47 20.7 16.3 2.07 2.00 21.1 17 2.11 2.04 21 17.5 2.67 2.37 22 18.7
Pf: total cooling capacity Tal: in flow air temperature dpw: pressure drop standard coil
Twi: in flow fluid temperature Qw: fluid flow rate in heat exchanger Qa: air flow
Pfs: sensible cooling capacity Tad: discharge air dry temperature Taw: discharge air wet temperature
Note
: For cooling condition: temperature different between incoming/outgoing water is 5 degree Celsius.
Design and specification are subject to change without prior notice for product Improvement.
