Foundation FP-102KM4 - Installation Method

Page 16 of 49
Ceiling cassette
Fan
Coil Unit
, 4
-
pipe system
Model: FP-
KM
• Ensure there is sufficient space around the unit to service it. See Fig.3
INSTALLATION METHOD
• Using the installation template open ceiling panels and install the suspension bolts as in Fig.4 below
590×590: Dimensions for opening
616×280: Suspension Bolts
MODELS
FP-68KM4
FP-80KM4
Fig.3
