Ceiling cassette
Fan
Coil Unit
, 4
-
pipe system
Model: FP-
KM
mounting brackets
control box
0 0
8 0
750×750: Dimensions for opening
440×776: Suspension Bolts
MODELS
FP- 85KM4
FP-102KM4
FP-136KM4
880× 880: Dimensions for opening
395× 880: Suspension Bolts
MODELS
FP-170KM4
FP-204KM4
FP-238KM4
• Mark position of suspension rods, water lines and condensate drain pipe, power supply cables and
remote control cable.
Supporting rods can be fixed, depending on the type of ceiling, as shown in Fig. 5 and Fig.6.
• Fit suspension brackets supplied with the unit to the threaded rods (Fig.7).
Do not tighten nuts and counter nuts; this operation has to be done only after final leveling of the unit,
when all the connections have been completed.
Fig. 4
Fig. 5 Fig. 6
395
880
