2.J AUXILIARY CONTACTS
• Cool and dehumidification mode (AUX2)
AUX2 is closed when MTV2 is on (in normal operation). AUX2 is opened when MTV2 is off or protection
of indoor coil is operating.
• Ventilation mode (AUX1 and AUX2)
AUX1 and AUX2 are opened when Indoor fan is on.
• Heat mode (AUX1)
AUX1 is closed when MTV1 is on (in normal operation). AUX1 is opened when MTV1 is off or protection
of indoor coil is operating.
2.K SLEEP FUNCTION
• Sleep function can only be set in cool or heat modes.
• In cool mode, after sleep function is set, the indoor fan will run at low speed and Ts will increase 2°C
during 2 hours.
• In heat mode, after sleep function is set, the indoor fan will run at auto fan mode and Ts will decrease 2°C
during 2 hours.
• Changing of operation mode will cancel sleep function
The COOL mode SLEEP profile is as follow:
+2
+1
Ts
