605-01-323 2
SUPPLIED PARTS
SHOCK ASSEMBLY
FOX PN DESCRIPTION QTY NOTES
983-06-190-L/R FRONT, LEFT/RIGHT SHOCK 2 4WD, 4-6” Lift
983-26-119 REAR, LEFT/RIGHT SHOCK 2 4-6” Lift
983-06-181-L/R FRONT, LEFT/RIGHT SHOCK 2 4WD, 0-2” Lift
983-26-114 REAR, LEFT/RIGHT SHOCK 2 0-2” Lift
983-06-189-L/R FRONT, LEFT/RIGHT SHOCK 2
2WD, 0-2” Lift
FRONT RESERVOIR BRACKET ASSEMBLY
FOX PN DESCRIPTION *HARDWARE REF. QTY NOTES
026-01-073 FRONT RESERVOIR MOUNT A 2
Brackets mount the
remote reservoirs to
the vehicle.
018-01-049 SCREW: 1/4”-14 X 3/4” HEX HEAD, SELF-TAPPING B 2
Each bracket uses
one self-tapping
screw.
018-01-066 SCREW: 8-32, 3/4” C1 8 Each bracket uses
two clamps and
a clamp uses two
screws.
026-01-167-1 2.5 RESERVOIR CLAMP, TOP C2 4
026-01-167-2 2.5 RESERVOIR CLAMP, BOTTOM C3 4
FRONT TOP HAT HARDWARE
FOX PN DESCRIPTION *HARDWARE REF. QTY NOTES
018-05-030-A WASHER: M10 D1 6 Each top hat uses
three washers and
three nuts.
019-00-013 HEX NUT: M10 X 1.25” D2 6
FRONT LOWER CONTROL ARM HARDWARE
FOX PN DESCRIPTION *HARDWARE REF. QTY NOTES
018-04-036 BOLT: M12 X 1.75” E2 4 Each bar-pin utilizes
two washers and
two bolts.
018-05-026-A WASHER: M12 E3 4
*Hardware Reference is used throughout the installation manual to provide notation of the supplied kit.
