605-01-323 3
SHOCK DIAGRAM
1
1
11
14
4
4
5
5
3
8
7
9
12
8
9
12
10
10
11
13
6
2
PART NO. NAME PART NO. NAME
1 Eyelet 8 DSC adjuster
2 Reservoir bridge 9 Reservoir
3 Hose 10 Bumper
4 Wiper seal 11 Shock body
5 Shaft 12 Schrader valve
6 Hose coupler 13 Top hat
7 Preload ring 14 Bar-pin bolt
FRONT SHOCK
REAR SHOCK
