35
Heavy package. Two persons must transport the machine.
Product in compliance with relative CE regulations.
Double insulation. This symbol means that you cannot get at any element without
using a tool. Tools which have this symbol have not any earthing protection
systems.
Serial number / year of production
ELECTRICAL CONNECTION
ELECTRICAL CONNECTIONS
Use 230 V 50 Hz alternate voltage equipped with a earthing conductor to supply your
machine. Ensure that the power supply corresponds to this voltage, that it is protected by a
differential and magnetothermal switch, and that the earthing system is efficient. If your
machine does not work when connected to a socket, check carefully the power supply
features.
Use an extension cable in order to connect the machine to the power supply.
EARTHING INSTRUCTIONS
If the tool does not work properly or in case of short-circuit, the earthing system provides the
current with a less resistance path and reduces the risk of electric shock. This tool has a plug
to which a supply or extension cable must be connected, which in turn must be connected to
a socket correctly installed and earthed, in conformity with local standards and regulations.
Be sure that your earthing system is in good conditions and that your plug is protected by a
differential and magnetothermal switch.
Do not modify the plug of the machine. If it does not enter the socket, get a suitable plug
installed by a qualified person. If the earthing conductor is not correctly connected the risk of
electric shock can occur. The conductor which has the green insulating jacket (with or without
Socket with earthing
system
Earth conductor
Machine’s plug
