13
661M03 Series User Manual
Chapter 2 Installation Instructions
Attention:
1.Push down the locks on the retention mechanism to secure
the heatsink and fan to the module base.
2.When secured, the retention locks should point to opposite
directions.
CPU Qualified Vendor List
The following table lists the CPU modules that have been tested and quali-
fied for use with this motherboard.
Vendor Type FSB Frequence
Intel Pentium (Northwood) 400 MHz 2.0GHz, 2.5GHz
Intel Pentium (Northwood) 533 MHz 2.4GHz, 2.66GHz, 2.8GHz, 3.06GHz
Intel Pentium (Northwood) 800 MHz 2.4GHz, 2.6GHz, 3.0GHz
Intel Pentium (Prescott) 800 MHz 2.8GHz
Intel Celeron (Northwood) 400 MHz 2.0GHz, 2.1GHz, 2.4GHz
Intel Willamette 400 MHz 1.8GHz
