661M03 Series User Manual
Chapter 2 Installation Instructions
LAN connector
This port allows connection to a Local Area Network (LAN) through a network hub.
Line-in jack, Line-out jack, Microphone jack
When using a two-channel sound source, the Line-out jack is used to connect
to speakers or headphones; the Line-in port connects to an external CD player,
tape player or other audio device. The Microphone jack is used to connect to the
microphone.
When using a 6-Channel sound source, connect the front speaker to the green
audio output; connect the surround sound speaker to the blue audio input;
connect the center speaker/subwoofer to the red Microphone input, as shown
in the following figure:
8
9
Line-out
(Front channels)
Line-in
Microphone
Front Left
Front Right
Rear Left
Rear Right
Subwoofer
Center
Blue
Green
Red
To Next Page
