Foxconn 945G7AD User Manual

Chapter 4 Driver CD Introduction
49
Utility CD content
This motherboard comes with one Utility CD. To begin using the CD, simply
insert the CD into your CD-ROM drive. The CD will automatically displays the
main menu screen.
1. Install Driver
Using this choice, you can install all the drivers for your motherboard. You should
install the drivers in order and you need to restart your computer after the drivers
all installed.
A.Intel Chipset Driver B.Realtek (HDA) Audio Driver (optional)
C.Realtek LAN Driver D.Intel VGA Driver (optional)
E.Intel RAID Driver (optional) F.JMB RAID Driver
2. Utility
Use this option to install additional software programs.
A.FOX ONE B. Fox LiveUpdate
C.Microsoft DirectX 9.0 D. Adobe Acrobat Reader
E.Norton Intel Security F. Creat RAID Driver Floppy
G. Intel RAID Utility (optional)
3. Click on dynamic Foxconn Logo to visit our homepage.
PDF 文件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Foxconn 945G7AD Specifications

General

Form Factor	Micro ATX
Chipset	Intel 945G
Socket	LGA 775
Supported CPU	Intel Core 2 Duo, Pentium D, Pentium 4, Celeron D
Front Side Bus	1066/800/533 MHz
Maximum Memory	4 GB
PCI Express x16 Slots	1
Audio Chipset	Realtek ALC883
Integrated Graphics	Intel GMA 950
Memory Standard	DDR2 667/533
SATA	4
IDE	1
LAN Chipset	Realtek
LAN Speed	10/100 Mbps
USB Ports	8 (4 on back panel, 4 via headers)
Audio Channels	8-Channel
Back Panel Ports	PS/2, VGA, USB, LAN, Audio
