Chapter 1 Product Introduction
4
Layout
16. Front USB Connectors
17. BIOS TBL Protect Jumper (optional)
18. TPM Connector
19. Chassis Intruder Connector
20. SYS_FAN1 Connector
21. COM2 Connector
22. SATA II Connector
23. 24-pin ATX Power Connector: PWR2
24. FDD Connector
25. IrDA Header
26. DDR2 DIMM Slots
27. CPU_Fan Connector
28. North Bridge: Intel
®
945P/945G Chipset
29. LGA 775 CPU Socket
30. 8-pin ATX_12V Power Connector: PWR1
1. PCI Express x16 Slots
2. 1394a Connector (optional)
3. PCI Express x1 Slots
4. South Bridge: Intel
®
ICH7/ICH7R Chipset
5. PCI Slots
6. AUX-IN Connector (optional)
7. CD_IN Connector
8. Front Audio Connector
9. SPIDF_OUT Connector
10. Speaker Connector
11. IDE Connector: PIDE
12. Front Panel Connector
13. SPI Connector (optional)
14. J1 Connector (optional)
15. Clear CMOS Jumper
Note: The above motherboard layout is provided for reference only, please refer
to the physical motherboard.
6
5 4
3
2 1
7
8
9
10
11
12
13
14
15
16
17 18 1920 21 22 23 24
25
26
27
28
30
29
