Chapter 1 Product Introduction
2
Main Features
Size
· ATX form factor of 12 inch x 9.6 inch
Microprocessor
· Supports Intel
®
Core
TM
2 Extreme Edition,Core
TM
2 Duo,Pentium
®
D,Pentium
®
4 Extreme Edition,Pentium
®
4,Celeron
®
D processors in an LGA775
package
· Supports FSB at 533 MHz /800 MHz /1066 MHz
Chipset
· Intel
®
945P/945G (North Bridge) + ICH7/ICH7R (South Bridge)
System Memory
· Four 240-pin DIMM slots
· Supports Dual-Channel DDR2 667/533/400
· Supports up to 4GB DDR2 memory
USB 2.0 Ports
· Supports hot plug
·Eight USB 2.0 ports
· Supports wake-up from S1 and S3 mode
·Supports USB 2.0 protocol up to 480Mbps transmission rate
Onboard Serial ATA II
· 300MBps data transfer rate
· Supports RAID 0, RAID 1, RAID 10 (only for ICH7R)
·Four internal Serial ATA II connectors and one external Serial ATA II connector
Onboard LAN (-K)
· One LAN interface built-in onboard
· Supports 10/100/1000 Mbit/sec Ethernet
