Create RAID Ready
A "RAID Ready" system is a specic system conguration that, with the addition of
a second Serial ATA hard drive, can be seamlessly migrated to a conguration that
provides either improved storage performance or data protection from a single hard
drive failure.
1. Select [2] from the main menu, "Dene LD Menu" appears.
2. Press [Enter], the screen appears as below, select RAID Ready.
3. Use [↓] key to select the hard disk, press [Space] key to change its assignment
status to "Y".
4. Press [Ctrl-Y] to save the setting.
[ Dene LD Menu ]
LD No RAID Mode Total Drv Capacity(GB) Status
LD 1 RAID 0
2 163.99 Functional
LD 2 −−−− −−−− −−−−−−−− −−−−
LD 3 −−−− −−−− −−−−−−−− −−−−
LD 4 −−−− −−−− −−−−−−−− −−−−
LD 5 −−−− −−−− −−−−−−−− −−−−
LD 6 −−−− −−−− −−−−−−−− −−−−
LD 7 −−−− −−−− −−−−−−−− −−−−
LD 8 −−−− −−−− −−−−−−−− −−−−
LD 9 −−−− −−−− −−−−−−−− −−−−
LD10 −−−− −−−− −−−−−−−− −−−−
[↑] Up [↓] Down [ESC] Exit [Enter] Select
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ Keys Available ]
LD 1 −−−− −−−− −−−−−−−− −−−−
[ Dene LD Menu ]
[ Dene LD Menu ]
LD No RAID Mode Total Drv
LD 1 RAID READY 1
Stripe Block: NA Fast Init: ON
Gigabyte Boundary: NA Cache Mode: WriteThru
Channel :ID Drive Model Compatibilities Capacity(GB) Assignment
1 :Mas HDS728090PLA380 SATA 3G 82.34 N
2 :Mas WDC WD1200JD-98HBB0 SATA 1.5G 120.03 N
3 :Mas Hitachi HDT725025VLA3 SATA 3G 250.05 N
4 :Mas ST3320620AS SATA 1.5G 320.07 Y
[↑] Up [↓] Down [ESC] Exit [Space] Change [Ctrl-Y] Save [PgUp/Dn] Page Change
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ Keys Available ]
[ Dene LD Menu ]
[ Drives Assignment ]
Y
