Health
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main F-Center Chipset Boot Power Health Security Save & Exit
Case Open Warning [�isabled]
CPU Temperature : +45 C
System Temperature : +27 C
CPU Fan Speed : 3026 RPM
System Fan 1 Speed : N/A
System Fan 1 Speed : N/A
CPU Vcore : +0.924 V
V��R : +1.608 V
+12V SYS : +12.074 V
+5V SYS : +3.045 V
CPU Warning Temperature [�isabled]
CPU Shutdowm Temperature [�isabled]
CPU Smart Fan Control [�isabled]
System Smart Fan Fan Control [�isabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized �efaults
F4: Save & Exit
ESC: Exit
Enabled Case Open Warning
and open chassis,Intrusion
Alarm will appear.If don’t
enter bios setup and dis
-
abled Case Open Warning one
time,Intrusion Alarm don’t
clear,it will appear all the
time.
Health
This item is used to enable or disable case open warning function.
These items show the current CPU temperature detected automatically by the system.
These items show the current System temperature detected automatically by the system.
This item shows the current CPU Fan speed detected automatically by the system.
This item shows the current North Bridge Fan speed detected automatically by the system.
These items show the Current CPU Vcore/VDDR/+12V SYS/+5V SYS voltage detected auto-
matically by the system.
This option is used to set the warning temperature for the system. When the temperature ofThis option is used to set the warning temperature for the system. When the temperature of
CPU is higher than the set value, the motherboard will send out warning information.
This item is used to set the system temperature upper limit. When the temperature exceeds
the set value, the system will shut down automatically.
This function works only when your operating system is supporting ACPI.
This option is used to enable or disable smart fan function. Default value is [Disabled]. Only
when this option is enabled, you can set some correlative parameters. "Smart Fan Automatic
Mode" is the principle gure of CPU smart fan function for your reference.
The CPU fan/System speed are automatically detected and displayed by the system.
