3
35
This item is used to set the energy saving mode of the ACPI function. When you select “S1
(POS)” mode, the power is always on and computer can be resumed at any time. When
you select “S3 (STR)” mode, the power will be down after a period of time. The status of the
computer before it entering STR will be saved in memory, and the computer can quickly return
to previous state when the STR function wakes.
This item is used to enable/disable the PS2 keyboard/mouse to generate a wake up.
This item is used to wake up the system by a USB device when it is staying at S3 state.
This item is used to enable/disable the PCI Express device to generate a wake up.
This item is used to enable/disable the modem ring to generate a wake up.
This item is used to enable/disable the onboard LAN to generate a wake up.
This item is used to enable/disable RTC alarm event to generate a wake up.
RTC is system real time clock.
This item is used to enable/disable the EuP(Energy-using Products) feature. When enable, the
suspend power of the chipset will be cut off in S5 suspend mode in order to reduce the power
consumption of motherboard.
Enabled: S1/S3/S4 is normal, S5 wake up only by pressing the power button.
Disabled: Normal ACPI function.
This item is used to set which state the PC will take with when it resumes after an AC power
loss.
ACPI Sleep State [S3]
Resume By PS2 KB/Mouse [Enabled]
Resume By USB �evice(s) [Enabled]
Resume By PCIE �evice(s) [�isabled]
Resume By PCIE PME [�isabled]
Resume By Modem Ring [�isabled]
Resume By Onboard LAN [�isabled]
Resume By RTC [�isabled]
Energy-using Products [Enabled]
Restore AC Power Loss
