Foxconn B75MX-D User Manual

PRODUCT INTRODUCTION
2
(Continued on the next page)
1-1 Product Specications
CPU Support Intel
®
Ivy Bridge/Sandy Bridge LGA1155 Processors
Max processor power up to 95W
For the latest CPU information, please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel
®
B75
Memory
2x240-pinDDR3DIMMs
Support up to 16GB of system memory
Dual channel DDR3 1600(IVB)/1333 MHz architecture
Expansion Slots 1 x PCI Express X16 slot
-SupportPCIExpressGen25GT/sdatarate(SandyBridge)
-Support PCI Express Gen3 8GT/s data rate (Ivy Bridge)
1 x PCI Express X1 slot
-SupportPCIExpressGen25GT/sdatarate
2xPCIslot
Storage Intel® B75 chipset
-3xSATA2.0connectors(3Gb/sdatatransferrate)
- 1 x SATA 3.0 connectors (6Gb/s data transfer rate)
LAN Realtek RTL8111DP-VC-CG Gigabit LAN controller (B75MX-S)
Realtek RTL8111F-CG Gigabit LAN controller
(B75MX/B75MX-D/B75MX-D PA)
Support 10/100/1000Mbps
Audio RealtekALC662-VD0-GR
-HighDenitionAudio
-2/4/5.1-channel
-Support Jack-Sensing function
USB Supportupto6xUSB2.0ports(2rearpanelports,2onboardUSBheaders
supporting4extraports)
Supportupto4xUSB3.0ports(2rearpanelports,1onboardUSBheaders
supporting2extraports)
SupportUSB2.0protocolupto480Mb/s
Support USB 3.0 protocol up to 5Gb/s
Internal
Connectors
1x24-pinATXpowerconnector
1x4-pinATX12Vpowerconnector
3xSATA2.0 connector
1 x SATA 3.0 connector
2xUSB2.0headers(supporting4xUSBdevices)
1 x USB 3.0 header (supporting2xUSBdevices)
1xCPUFANheader(4-pin)
1xSystemFANheade(4-pin)
1 x Speaker header (Buzzer Reserved)

Foxconn B75MX-D Specifications

General

Brand	Foxconn
Model	B75MX-D
Category	Motherboard
Language	English
