Foxconn D42S 3.0 User Manual

2
1
1-1 Product Specications
CPU Intel
®
Atom
TM
D425 processor mounted onboard (D42S 3.0)
Intel
®
Atom
TM
D525 processor mounted onboard (D52S 3.0)
Max processor power up to 17W
Chipset Intel
®
NM10 Express
Memory 2 x 240-pin DDR3 DIMMs
Support up to 4GB of system memory
Single channel DDR3 800MHz architecture
Expansion Slots 1 x PCI slot
VGA Integrated Intel
®
GMA950 GPU
Support DirectX 9.0 compliant
Storage NM10 Express chipset:
- 2 x SATA 2.0 connectors 300MB/s data transfer rate
LAN Realtek 8112B Gigabit LAN chip
(Co-lay Realtek 8100 and 8103E 10/100Mb/s LAN chip)
Audio Realtek ALC662 audio chip:
- High Denition Audio
- 2/4/5.1-channel
- Support for S/PDIF Out
- Support Jack-Sensing function
USB NM10 Express chipset:
- Support up to 8 x USB 2.0 ports (4 rear panel ports, 2 onboard USB
headers supporting 4 extra ports)
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
2 x SATA 2.0 connectors
2 x USB 2.0 connectors (supporting 4 x USB devices)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front panel connector
1 x Front Audio connector
1 x S/PDIF_OUT connector
1 x Speaker connector
1 x Chassis intrusion alarm header
1 x COM2 connector
1 x TPM connector
1 x IR/CIR connector
(Continued on the next page)
