1-1 Product Specications
CPU Support Intel Ivy Bridge/Sandy Bridge LGA 1155 Processors,
Max processor power up to 95W
For the latest CPU information, please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel
®
H77
Memory 4 x 240-pin DDR3 DIMMs
Support up to 32GB of system memory
Dual channel DDR3 1066/1333/1600 MHz architecture
Expansion Slot 1 x PCI Express x 16 slot
1 x PCI Express x1 slot
2 x PCI slots
Storage H77 chipset:
- 4 x SATA 2.0 connectors (3Gb/s data transfer rate)
- 2 x SATA 3.0 connectors (6Gb/s data transfer rate)
LAN RTL8111E colay RTL8105E
Audio Realtek ALC662/ ALC888S Audio chip:
- High Denition Audio
- 2/4/5.1-channel (H77M)
- 2/4/5.1/7.1-channel (H77M-S)
- Support Jack-Sensing function
USB H77 chipset:
- Support up to 10 x USB 2.0 ports (6 rear panel ports, 2 onboard
USB headers supporting 4 extra ports)
- Support up to 4 x USB 3.0 ports (2 rear panel ports, 1 onboard
USB headers supporting 2 extra ports)
- Support USB 2.0 protocol up to 480Mb/s
- Support USB 3.0 protocol up to 5Gbs
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 2.0 connectors
2 x SATA 3.0 connectors
2 x USB 2.0 headers (supporting 4 x USB devices)
1 x USB 3.0 header (supporting 2 x USB devices)
1 x CPU fan header (4-pin)
2 x System fan headers (4-pin)
1 x Front panel header
1 x Front audio header
(Continued next page)
