Foxconn H77M Series User Manual

5
89
Reset Disks to Non-RAID
Reset RAID volume allows you to replace a failed disk with a new one, and the
operating system will rebuild the data later. For RAID0, reset a hard disk would totally
crash the system, but for RAID1, RAID10 and RAID5, they all can be rebuilt.
When rebuild is needed, you must rst install a new hard disk in your system before
getting into Intel
®
Matrix Storage Manager utility, because the utility will ask you which
hard disk the new rebuild will be performed.
Example 1. Reset a RAID0 system.
1. A TryRAID0 volume was built with two 149.0GB hard disks, we want to reset one of
them. Select “3. Reset Disks to Non-RAID” in main menu and press <Enter>.
1. Create RAID Volume 4. Recover Volume Options
2. Delete RAID Volume 5. Acceleration Options
3. Reset Disks to Non-RAID 6. Exit
RAID Volume :
None Dened.
Physical Devices:
ID Device Model Serial # Size Type/Status(Vol ID)
0 ST3320418AS 9VM8Y4D8 298.0GB
Non-RAID Disk
1
ST3160815AS 5RX4M04N 149.0GB Non-RAID Disk
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
[ MAIN MENU ]
1. Create RAID Volume
2. A warning message is displayed.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2. Delete RAID Volume 5. Acceleration Options
3. Reset Disks to Non-RAID 6. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
0 TryRAID0 RAID0(Stripe) 128KB 298.1GB
Normal Yes
0 Hitachi HDS72161 PVF904Z21G2JZM 149.0GB
Member Disk(0)
1
ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk
2
SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Member Disk(0)
3
ST380815AS 5RW1CA37 74.5GB Non-RAID Disk
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
Resetting RAID disk will remove its RAID structures
and revert it to a non-RAID disk.
WARNING: Resetting a disk causes all data on the disk to be lost.
( This does not apply to Recovery volumes)
Port Drive Model Serial # Size Status
0 Hitachi HDS721616PLA PVF904Z21G2JZM 149.0GB Member Disk
2
SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Member Disk
Select the disks that should be reset.
[↑↓]-Previous/Next [SPACE]-Selects [ENTER]-Selection Complete
0 Hitachi HDS721616PLA PVF904Z21G2JZM 149.0GB Member Disk
[ RESET RAID DATA ]
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 4. Recover Volume Options
2. Delete RAID Volume 5. Acceleration Options
3. Reset Disks to Non-RAID 6. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
0 TryRAID5 RAID5(Parity) 64KB 149.1GB
Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 Hitachi HDS72161 PVF904Z21G2JZM 149.0GB
Member Disk(0)
1
ST380811AS 5PS1TAGW 74.5GB Member Disk(0)
2
SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Member Disk(0)
3
ST380815AS 5RW1CA37 74.5GB Non-RAID Disk
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-09 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
3. Reset Disks to Non-RAID
