Foxconn H77M Series User Manual

3
30
► Four Active Window (tFAWmin)
This item allows you to specify the time window in which four activates are allowed the same
rank.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main F-Center Chipset Boot Power Health Security Save & Exit
▶ North Bridge
▶ ME Subsystem
▶ Onboard Device Configuration
▶ SATA Configuration
▶ Super IO Configuration
▶ Trusted Computing
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
North Bridge Parameters
Advanced
► North Bridge/ME Subsystem/Onboard Device Conguration/SATA Conguration
/Super IO Conguration/ Trusted Computing
Press <Enter> to go to its submenu.
North Bridge
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
North Bridge Configuration
Memory Information
Total Memory 1024 MB (DDR3 1333)
Memory Slot1 Not Present
Memory Slot2 Not Present
Memory Slot3 1024 MB (DDR3 1333)
Memory Slot4 Not Present
Memory Configuration
Integrated Graphics [Auto]
UMA Frame buffer size [64M]
Initate Graphics Adapter [Auto]
VT-d [Enabled]
IGD Multi-Montior [Disabled]
DVMT/FIXED Memory [256M]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Keep IGD enabled based on the
setup options.
Advanced
