3
29
North Bridge Conguration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Memory Multiplier Configuration
Performance Memory Profiles [Manual]
XMP Profile 1 Not Supported
XMP Profile 2 Not Supported
Memory Timing Configuration
Memory Clock Multiplier [1.33]
Memory Multiplire [13.33]
tCL 9
tRP 9
tRCD 9
tRAS 24
tWR 10
tRFC 74
tWTR 5
tRRD 4
tRTP 5
tFAW 20
Intel Graphics Configuration
Graphics Core Ratio Limit 10
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
The selection of Performance
Memory Profiles which impacts
memory sizing behavior.
F-Center
► CAS Latency (tCL)
The number of memory clocks it takes a DRAM to return data after the read CAS_L is assert
ed depends on the memory clock frequency. The value that BIOS programs into the memory
controller is a function of the target clock frequency. The target clock frequency is determined
from the supported CAS latencies at given clock frequencies of each DIMM.
► Row Precharge Time (tRPmin)
This item allows you to select the row precharge time (in clock cycles).
► CAS to RAS(tRCDmin)
This item allows you to select a delay time (in clock cycles) between the CAS# and RAS#
strobe signals.
► Active to Precharge(tRASmin)
This item allows you to set the minimum RAS# active time (in clock cycles).
► Write Recovery(tWRmin)
This item allows you to select the write recovery time (in clock cycles).
► Refresh Recovery(tRFCmin)
Refresh to Refresh or Refresh to Active command interval.
► Internal Write to Read Command(tWTR)
This item allows you to select a delay time (in clock cycles) between sending the last data from
a write operation to the memory and issuing a read command.
► Row Active to Row Active(tRRDmin)
This item allows you to select a delay time (in clock cycles) between the RAS# and RAS#
strobe signals.
► Read CAS# Precharge Delay (tRTP)
Internal READ Command to PRECHARGE Command delay
To Next Page
