Foxconn H77M Series User Manual

3
28
North Bridge Conguration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Memory Multiplier Configuration
Performance Memory Profiles [Automatic]
XMP Profile 1 Not Supported
XMP Profile 2 Not Supported
Intel Graphics Configuration
Graphics Core Ration Limit 5
Graphics Voltage(1/256) 0
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
The selection of Performance
Memory Profiles which impacts
memory sizing behavior.
F-Center
► Performance Memory Profiles
This item is used to select Performance memory prole.
Options:[Automatic], [Manual], [XMP Prole 1], [XMP Prole 2].
[Automatic]- Conguration database of using performance memory prole.
[Manual]- Conguration database of using performance memory prole. The next submenu
will appear when select this item.
[XMP Prole 1]-Conguration database of using XMP timing prole 1.
[XMP Prole 2]- Conguration database of using XMP timing prole 1.
► Graphics Core Ration Limit
This item is used to set Graphics Core Ratio Limit
► Graphics Voltage(1/256)
This item is used to set Graphics Voltage(1/256)
