Foxconn H77MXV-D User Manual

BIOS SETUP
34
Boot
Version 2.14.1219. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main F-Center Advanced Boot Power Health Security Save & Exit
Boot
Boot Configuration
Bootup Numlock State [On]
Quiet Boot [Enabled]
Interrupt 19 Capture [Enabled]
Set Boot Priorities
1st Boot [Hard Disk]
2nd Boot [Optical Disk]
3rd Boot [Removeable]
4th Boot [Network]
5th Boot [UEFI]
▶ Hard Disk Drive Priority
▶ Optical Disk Drive Priority
▶ Removeable Device Priority
▶ Network Device Priority
▶ UEFI Boot Device Priority
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Select the keyboard NumLock
state
►BootupNumlockState
This item is used to select the keyboard numlock state. The defaulte setting is [On].
►QuietBoot
This item is used to enable/disable the quiet boot.
[Disabled] : Displays the normal POST messages.
[Enabled] : Displays OEM customer logo instead of POST messages.
►Interrupt19Capture
Enable this item can allow Option ROMs to trap Interrupt 19.
►SetBootPriorities
These items are used to set the system boot order.
►HardDiskDrivePriority
Thsi item is used to specify the Boot Device Priority sequence from available Hard Drives.
►OpticalDiskDrivePriority
This item is used to specify the Boot Device Priority sequence from available Optical Disk
Drives.
►RemoveableDevicePriority
This item are used to specify the Boot Device Priority sequence from available Removeable
Drives.
►NetworkDevicePriority
This item are used to specify the Boot Device Priority sequence from Network Boot Drives.
►UEFIBootDevicePriority
This item are used to specify the Boot Device Priority sequence from UEFI Boot Drives.
