RAID CONFIGURATION

Create RAID 1

1. Select “1.Create RAID Volume” from the main menu and press <Enter>.

2.In"Name"item,youcaninputadevicenamefortheRAID1systemandpress<Enter>to

apply it. Here, we name it as TryRAID1 to replace the default Volume0.

Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5

Copyright(C)2003-04IntelCorporationAllRightsReserved.

Enter a unique volume name that has no special characters and is

16 characters or less.

Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204

[ CREATE VOLUME MENU ]

[ HELP ]

Name:

RAID Level:

Disks:

Strip Size:

Capacity:

Sync:

Volume0

RAID0(Stripe)

Select Disks

128KB

0.0 GB

N/A

Create Volume

TryRAID1

[↑↓]-Change[TAB]-Next[ESC]-PreviousMenu[ENTER]-Select

3. In “RAID Level” item, you can use Up or Down arrow key to make a selection. Select RAID1

(Mirror) and press <Enter>.
