Foxconn H77MXV-D User Manual

RAID CONFIGURATION
74
CreateRAID0(2ndVolume)
1. Select “1. Create RAID Volume” from the menu and press <Enter>. The menu appears :
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
Enter a unique volume name that has no special characters and is
16 characters or less.
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
[ CREATE VOLUME MENU ]
[ HELP ]
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Sync:
Volume0
RAID0(Stripe)
Select Disks
128KB
0.0 GB
N/A
Create Volume
Volume0
[↑↓]-Change[TAB]-Next[ESC]-PreviousMenu[ENTER]-Select
2.In"Name"item,wenameitasTryRAID0-1forsecondvolume.
3. In “RAID Level” item, you can use Up or Down arrow key to make a selection, only RAID0, 1
can be selected. Select RAID0 (Stripe) and press <Enter>.
(Note : You also can try to select RAID1 for the second volume as an experiment here)
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
RAID 0: Stripes data (performance).
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
[ HELP ]
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Sync:
TryRAID0-1
RAID0(Stripe)
Select Disks
128KB
0.0 GB
N/A
Create Volume
RAID0(Stripe)
[↑↓]-Change[TAB]-Next[ESC]-PreviousMenu[ENTER]-Select
[ CREATE VOLUME MENU ]
4.Itthengoesto“Disks”item.Press<Enter>todisplaytheharddiskslistforthisRAID0 
second volume system.
