Foxconn H77MXV-D User Manual

RAID CONFIGURATION
84
6. Use Up or Down arrow key to select the desired strip size when entering “Strip Size” menu.
 Thedefaultvalueis64K.Press<Enter>.
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
The following are typical values:
     RAID0-128KB
     RAID10-64KB
     RAID5-64KB
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Sync:
TryRAID5
RAID5(Parity)
Select Disks
128K
149.1GB
N/A
Create Volume
[↑↓]-Change[TAB]-Next[ESC]-PreviousMenu[ENTER]-Select
[ HELP ]
64KB
[ CREATE VOLUME MENU ]
7. In “Capacity” item, use the default value, and press <Enter>. The default value is twice that
 ofthesmallestharddisksize,thatis,74.5GB*2=149GB.
8. Select “Create Volume” and press <Enter>. A warning message will appear :
WARNING:ALLDATAONSELECTEDDISKSWILLBELOST.
Are you sure you want to create this volume ? (Y/N) :
Press <Y> to create the volume and return to the main menu.
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
     4.RecoverVolumeOptions
  2.DeleteRAIDVolume  5.AccelerationOptions
3. Reset Disks to Non-RAID 6. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRAID5  RAID5(Parity)64KB 149.1GB Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 HitachiHDS72161 PVF904Z21G2JZM 149.0GB Member Disk(0)
1
ST380811AS 5PS1TAGW 74.5GB Member Disk(0)
 2
SAMSUNG HD161HJ  S0V3J9APA30524 149.0GB Member Disk(0)
3
ST380815AS 5RW1CA37  74.5GB Non-RAID Disk
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
[DISK/VOLUMEINFORMATION ]
[ MAIN MENU ]
1. Create RAID Volume
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
