Foxwell F1000B - Display Test; Keypad Test

Foxwell F1000B OBDII&Battery Tester User’s Guide_ English Version_V1.00
50
● Keypad Test
● LED Test
9.6.1 Display Test
Selecting Display Test option opens a screen that allows you to check the functionality of the
display.
To test the display:
1. Use the UP/DOWN key to highlight Display Test from Setup menu and press the ENTER key
to start test.
Figure 8-19 Sample Tool Self-test Screen
2. Check if there are any missing spots in the LCD screen.
Figure 8-20 Sample LCD Test Screen
3. To quit the test, press the BACK key.
9.6.2 Keypad Test
Selecting Key Test option opens a screen that allows you to check the functionality of the keypad.
To test the keypad:
1. Use the UP/DOWN key to highlight Keyboard Test from Setup menu and press the ENTER
key.
