FP Zoom TTL - Component Identification; Flash Body Parts; Control Panel Layout

03
22 23
24
16
19
18
17
21
15
20
01. Retractable Bounce Card
02. Retractable Wide Angle Diuser
03. Flash Head
04. Optical Control Sensor
05. Focus Assist Beam
06. R1 Wireless Control Port
07. Sync Cord Jack
08. Hotshoe
09. Dot-marix LCD Panel
10. Lock Ring
11. Battery Compartment
12. USB Port for Firmware Upgrades
13. Slave Flash Ready Indicator
14. External Power Supply Socket
Body
Name of Parts
06
07
12
08
04
05
13
14
03
01
09
11
10
02
Control Panel
15. < MODE > Mode Selection
Button / Lock Button
16. < > Wireless Selection
Button
17. Select Dial
18. < SET > Set Button
19. ON / OFF Power Switch
20. < > Test Button / Flash
Ready Indicator
21. Function Button 1
22. Function Button 2
23. Function Button 3
24. Function Button 4
