RM 2106 / 2112
18
If the terminal ”Meas” is used, the voltage
for terminals ”Meas” and ”L” must be
connected each to a phase conductor.
For all types of connections (gure 3 to 6)
it is also possible to connect the current
transformer in phase conductors L2 or L3.
In this case, the voltage connections to the
phase conductors should be exchanged
accordingly.
If the control relay operates with automatic
response current recognition, connection
errors would be reported.
If response current recognition is deactivated,
then an error in the connection will lead
to functional errors during subsequent
operation.
