Technical Data
41
8 Technical Data
Mode of Connection:
As shown in connection diagrams 3 to 6
Operating Voltage:
Supply voltage Absolute permissible
threshold values
220 - 240 V AC 195 ... 264 V AC
Frequency:
50 Hz / 60 Hz (48 to 62 Hz)
Consumption of supply voltage:
Approx. 4 VA
Current path:
For current transformer: ... / 1 A AC to ... / 5 A AC
Permissible maximum current: 6 A~
Consumption in current path:
max. 0.5 VA at 5 A AC
Measuring voltage at terminal ”Meas”:
Maximum 264 V AC at terminal ”N”
Control Contacts:
RM 2106: 6 switching contacts
RM 2112: 12 switching contacts
with potential binding to supply voltage
(terminal „L“)
Loading Capacity of the control contacts:
per contact (max.) 2 A
(only ohmic or inductive load)
total contact current (max.) 4 A
total contact load (max.) 950 VA
No-voltage Trip
(Undervoltage monitoring):
With voltage drops under 170 V for more
than 10 ms all capacitor stages connected
are switched off. After voltage is restored the
control relay switches the required stages on.
Zero current trip:
For a current loss of longer than 3 seconds
all capacitor stages connected are switched
off. After current is restored the control relay
switches the required stages on.
Discharge time for the capacitors:
min. 1 min.
Controls:
Keypad with 2 keys
Indicator elements:
RM 2106: 12 LEDs
RM 2112: 18 LEDs
3 character digital display
Operating temperature range:
-25 ºC to +60 ºC
