frako RM 9606 - Programming Modes - Core Settings; Target Power Factor and Parallel Shift; Limitation, Time Delay, c;k Identification

15
Table 1: Programming of Values
Programme
Mode No.
Description Pre-programmed
standard Value
Programme Range
-01- Target Power
Factor
Ind. 0.92 from cap. 0.90 to ind. 0.8 in
increments of 0.01 steps
-02-
Parallel Shift PS
-
1.0 (Target Power
Factor is lower
than limit value)
from –2 to +4 in increments
of 0.5 steps
-03- Limitation L +1.0
(Overcompensation
is avoided)
from –2 to +2 in increments of
0.5 steps
-04- Switching time
delay in
seconds
45 5 to 500 seconds in 1 sec. steps
or at a high speed
in 5 sec.steps.*)
-05- Automatic c/k
Identification
ON ON=automatic mode
OFF=manual mode
When “ON“, the programme
switches directly to programme
mode no. -09-
-06- Manual c/k
Value setting
2.0 From 0.02 to 2.0 in 0.01 steps or
At high speed in 0.05 steps.*)
-07- Switching se-
quence
1:1:1:1:1
1:1:1:1:1:1
1:1:2:2:2:2
1:1:2:2:4:4
1:1:2:3:3:3
1:1:2:4:4:4
1:1:2:4:8:8
1:2:2:2:2:2
1:2:3:3:3:3
1:2:3:4:4:4
1:2:3:6:6:6
1:2:4:4:4:4
1:2:4:8:8:8
-08- Number of con-
tactors used
6 From 1 to 6
-09- Determination of
Fixed stages
0 0= no fixed stage
1= output fixed
2= outputs 1 and 2 fixed
3= outputs 1 to 3 fixed
*) by pressing the buttons "+" or "-" for some time, the high speed mode will be activated.
