Framery O
12 Reassemble
12.1 Install the floor cover panels
Install the floor cover panels (2 pcs) with 5x60 countersunk screws (2 pcs each).
Note: Place the countersunk holes upwards. Use the existing screw holes.
12.2 Install the wall cover panels
Reinstall the wall cover panels (4 pcs) with 4x30 screws (6 pcs each).
Note: Make sure that you install the techwall panels on the left-hand edge of the
wall so that the power cord fits on the right-hand side.
Note: Make sure that the grooves in the panels are on the outer edge of the panel.
Place the countersunk holes upwards. Use the existing screw holes.
Complete care instructions
