Framery O
12.3 Install the roof cover panels
Install the roof cover panels (2 pcs) with 4x30 screws (2 pcs each).
Note: Place the countersunk holes upwards. Use the existing screw holes.
Note: If you installed the power cord to the roof module, make sure that it is in the
notch and is not damaged during the cover panel installation.
44
