Framery O
5. Tighten the set screw on the inside handle.
Note: Tighten the set screw. The resistance increases steadily until the screw
pierces the spindle. In the final position, the head of the set screw is left with
1-2 threads visible.
6. Install the upper cover plates with M4x30 screws (2 pcs).
Do not overtighten.
Note: Make sure that you install the smooth cover plate to the outside.
8.5 Replace the strike plate
34
Complete care instructions
