Framo Cargo Pump SD125-5/ SD150-5
INSTRUCTION FOR MAINTENANCE AND REPAIR
No.
Date/sign.:
Page:
Rev. B:
1000-0131-4
Jan99/AGAa
16 of 21
22Feb06/JEB
Remove if necessary shaft sleeve for mechanical oil seal by use of extractor.
Û¨¬®¿½¬±®º±®
-¸¿º¬-´»»ª»
Fig. 17
Replace if necessary the complete mechanical seal, and shaft sleeve. The shaft sleeve must be
heated to approximately 120!C prior to assembling. See instruction 0290-0036-4 for installation of
mechanical oil seal.
