Framo Cargo Pump SD125-5/ SD150-5
INSTRUCTION FOR MAINTENANCE AND REPAIR
No.
Date/sign.:
Page:
Rev. B:
1000-0131-4
Jan99/AGAa
3 of 21
22Feb06/JEB
1.1 Technical data SD125-5
PUMP TYPE: SD 125-5D*-HH***-***-*
DISCHARGE FLANGE CONNECTION: DN 125 PN 25 DIN2634
HYDRAULIC CONNECTIONS:
PRESSURE: DN 30 PN 320 FRAMO
RETURN: DN 40 PN 16 FRAMO
PILOT: DN 15 PN 320 FRAMO
AIR / INERT GAS CONNECTION:
FOR PURGING OF COFFERDAM: FRAMO QUICK COUPLING
MAX. CONSUMPTION, 10M PUMP 0.3 NM
3
FOR PURGING OF CARGOPIPE, PUMP: FRAMO QUICK COUPLING
MAX. CONSUMPTION, 10M PUMP: 1.0 NM
3
HYDRAULIC OIL VOLUME IN 10M PUMP: 44 LITRE (3 L/M)
RECOMMENDED HYDRAULIC OILS: SEE FRAMO LUBRICATION CHART
DESIGN PRESSURE:
CARGO 25 BAR
HIGH PRESSURE, HYDRAULIC: 320 BAR
RETURN PRESSURE, HYDRAULIC: 16 BAR
COFFERDAM: 7 BAR
WEIGHT OF PUMP AND PUMP PARTS:
PUMP COMPLETE: 10M: 520 KG
PUMP CASING: 320 KG
PUMP HEAD COMPLETE (without motor): 130 KG
BEARING HOUSING COMPLETE: 62 KG
HYDR. MOTOR, max. weight: 23 KG
VOLUTE CASING: 30 KG
IMPELLER: 10 KG
