Franconia FC 02 - GPIB Interface Details; RS-232 Serial Port; Optical Ports

[4]: IEEE-488 (GPIB)
24 pin Centronics connector. The GPIB interface Bus complies with the IEEE 488.2
standards. The FC 02 use the Standard Commands for Programmable Instruments (SCPI) and
the IEEE 488.2 protocol on which SCPI is based.
[5]: Serial connector (RS-232)
The RS 232 port is a standard serial port (Baud rate 9600) used for the manual mode or used
for upgrading the flash memory. The socket is a type Sub 9 pin female.
[6]: Optical in
F-SMA Receiver, 660nm
[7]: Optical out
F-SMA Transmitter, 660nm
