8.0 SCPI commands
Instrument subsystem:
Command Parameter Unit Result
INST[:SEL]{?}
INST:NSEL{?}
ANT / TTAB / ACL /
ANT2
1 / 2 / 3 / 4
Selection of the logical equipment by keyword or
number. On ? output of the selected logical device.
System subsystem:
Command Parameter Unit Result
SYST:ERR[:NEXT]? Query only Output and deletion of the last error in the error list.
SYST:VERS? Query only Output of the SCPI standard „1999.0“.
SYST:COMM:GPIB:ADDR{
?}
0...30 / MIN / MAX Setting of the GPIB address (saved in EEPROM,
default value: 15).
SYST:COMM:SER[:REC]
:BAUD{?}
1200 / 2400 / 4800 /
9600 / 19200 / MIN /
MAX
Setting of the RS232 baud rate (saved in EEPROM,
default value: 9600).
Status subsystem:
Command Parameter Unit Result
STAT:OPER[:EVEN]? Query only Output of the operation register.
STAT:OPER:COND? Query only Output of the operation condition register.
STAT:OPER:ENAB{?} 0...65535 Setting of the operation enable register.
STAT:QUES[:EVEN]? Query only Output of the questionable register.
STAT:QUES:COND? Query only Output of the questionable condition register.
STAT:QUES:ENAB{?} 0...65535 Setting of the questionable enable register.
STAT:PRES Reset of the operational/questionable enable
register.
Trigger subsystem:
Command Parameter Unit Result
INIT[:IMM] Starts a movement into the previously set direction.
ABOR Stops every started movement (even initialization
run).
Input/output subsystem for the antenna mast (ANT, ANT2):
Command Parameter Unit Result
POS[:X][:DIST][:IMM]{?} <NRf / 0.8...6> / MIN /
MAX / UP / DOWN
m The antenna mast moves to the programmed
position or direction, resp.. Upon inquiry, the actual
position is reported.
POS[:X][:DIST][:IMM]:STE
P{?}
<NRf / 0...5.2> / MIN /
MAX
m Step width at POS UP / DOWN command.
POS[:X][:DIST]:LIM[1/2]:HI
GH{?}
<NRf / 0.8...6> / MIN /
MAX
m
POS[:X][:DIST]:LIM[1/2]:LO
W{?}
<NRf / 0.8...6> / MIN /
MAX
m
Upper and lower limit value for the antenna with
horizontal [1] and vertical [2] polarization.
