-19011150- • Rev. C • June 14, 2018 5
CONTROLS & SETTINGS
Power ON/OFF Switch
NOTICE
NEVER turn power switch OFF when unit is in use!
Doing so may result in spoilage and loss of stored
food products.
The Convertible Cooler Freezer is provided with a
main power ON/OFF switch, mounted to the front of
the unit, above the two drawers (Fig. 3).
Fig. 3
POWER ON/OFF SWITCH
Factory Preset Temperature and
Adjustable Range
The temperatures for the Convertible Cooler Freezer
are preset at the factory. The preset temperatures
are recommended for normal operation. If needed,
the temperatures can be adjusted. The factory pre-
sets and adjustable ranges are shown in the following
table (Table 2).
FACTORY PRESET
TEMPERATURE
ADJUSTABLE
TEMPERATURE RANGE
Refrigerator
Mode
37.5° F (3° C)
32.5° to 41.5° F
(0° to 5° C)
Freezer
Mode
-5° F (-20.5° C)
-2° to -8° F
(-19° to -22° C)
Table 2
Unit Temperature Adjustment
NOTICE
Only one controller at a time will be powered ON. The
controller for the mode not in use will remain powered
OFF until the refrigeration mode is switched.
To adjust the temperatures of the unit:
1. Locate the appropriate temperature controller on
the front of unit (Fig. 4 and 5).
Fig. 4 Temperature Controls (2DCV-30)
REFRIGERATOR
CONTROLLER
FREEZER
CONTROLLER
Fig. 5 Temperature Controls (2DCV-18)
REFRIGERATOR
CONTROLLER
FREEZER
CONTROLLER
1. Press SET (Fig. 6).
Fig. 6
2. Press SET again. The current setpoint is displayed.
Press the UP and DOWN arrow buttons to adjust
the temperature setting (Fig. 7).
