1T 310'177 Operating Manual Ecolino Erstellt: 01.05.2002 Rev.: C SL: 20'987 BJC
page 19
4. Pull out brewing piston and brewing table using a damp cloth (Figure 4).
5. Remove the grounds container by raising the tea and steam tube and empty. Then thoroughly
wash out the grounds container and dry it with a cloth (Figure 5).
6. Remove remaining dirt using a cloth (Figure 6).
7. Insert grounds container by raising the tea and steam tube (Figure 7).
8. Close the door (Figure 8). clean
locked selection
9. After the door has been closed, the display shows the
following after approx. 2 seconds: clean
cleaning tablet
10. Drop in tablet through filling funnel (Figure 9
11. Press Clean key (Figure 10). clean
locked selection
12. The automatic cleaning is started and takes from about 1 min to 6 min, depending on the number
of programmed cleaning cycles.
13. When cleaning is complete, remove and clean drip grille. Remove remaining dirt from the drip
tray using a cloth. Then rinse the drip tray with water and dry with a cloth. Insert drip grille again.
If the Ecolino is switched off during cleaning, the cleaning programme automatically
starts when the Ecolino is switched on.
Figure 4 Figure 5 Figure 6 Figure 7
Figure 8 Figure 9 Figure 10
