F3D3 Series Service Manual Refrigeration / Section 4.3
Questions? Call Franke Technical Support Group For Your Area. Copyright 2012 Franke, Inc. All rights reserved.
To Replace Start Relay…Continued:
Test operation of Compressor by:
19) Plug in unit to power source.
20) Turn ON unit at Main Power-ON Switch.
21) If compressor starts and runs, proceed to Step 22.
22) Replace and secure right side access panel using
screws removed earlier; and return Dispenser to normal
operating position.
[Photo 5]
Use Phillips screwdriver to
remove two screws that mount
relay to electric enclosure.
Rev. 1 6/2012
Medium Phillips screwdriver
Needle nose pliers
To Next Page
