Franke F3D3P Service Manual (English)

Other manuals for Franke F3D3P

User Manual34 pages

Operator's Guide32 pages

Questions and Answers:

P
Phyllis BooneSep 14, 2025
Why individual lanes of my Franke F3D3P Dispenser will not turn on?
- L
  lmillerSep 14, 2025
  If individual lanes won't turn on, ensure the main power is on by pressing the power switch to the 'ON' position. The rocker switch should illuminate. Allow 3 hours for cool-down before adding product. Also, check if the machine is plugged into a 120VAC or 230V/50Hz outlet as per the data plate and the main power switch is on. Finally, make sure you hold the LANE ON/OFF touch pad long enough (four seconds) until the two green lights come on.
B
Brittany SandovalAug 25, 2025
Why is my Franke F3D3P Dispenser freezer not cold enough?
- S
  Sean HaynesAug 25, 2025
  If your Franke Dispenser freezer is running but not reaching the required temperature of -18°C, consider the following: * Check for ice formation on the inside walls, especially on the temperature sensor. If there's ice, remove all items from the appliance and defrost it. To prevent ice buildup, avoid leaving the freezer door open longer than necessary and defrost daily. * Inspect the filter for soiling and clean it if necessary. * Examine the condenser ribs for soiling and clean them if needed.
S
steven87Aug 25, 2025
What to do if Franke F3D3P shows Err04 and won't dispense?
- R
  Robert JosephAug 26, 2025
  If your Franke Dispenser isn't dispensing and shows error message Err04, it means: * The hopper is empty. You should fill the hopper with fries and press the [Reset] button to begin the filling process. * Fries are baked together in the hopper forming a hard "bridge". You should shake the hopper to redistribute the fries and break up the clumps, carefully so as not to break the fries. If necessary, remove very hard clumps, then press [Reset] to start the filling process.
C
chapmanleeAug 26, 2025
Why is the reset button flashing on my Franke F3D3P?
- W
  williamrayAug 26, 2025
  If the ACTION-3 [Reset] button on your Franke Dispenser is flashing, it indicates: * The filling process was prematurely aborted. Press the [Reset] button to restart the filling process. * Fries in the hopper have formed a "bridge." Shake the hopper to redistribute the fries, carefully breaking up any clumps.
F
fpopeSep 14, 2025
What to do if Franke F3D3P Dispenser lane is empty but Err04 error doesn't appear?
- P
  Phillip ThomasSep 14, 2025
  If a lane is empty but the Err04 error message doesn't appear, there might be debris caught in the Low Product sensor hole, or the hopper may have shifted forward on the hanger. Remove any debris trapped in and around the low product sensor. Also, push the hopper into the freezer as far as it will go.
J
Jared MatthewsSep 8, 2025
Why Franke Dispenser freezer won’t run when turned on?
- J
  Juan DixonSep 9, 2025
  If the freezer won’t run when the main power is turned on, check that the unit is properly plugged in and the main power switch is in the ON position. Also, verify that the wall outlet is working, and the circuit breaker hasn't been tripped. Try plugging the freezer into another outlet and reset the circuit breaker if needed. If the outlet isn't working, contact a licensed electrician.
J
Jill TurnerSep 7, 2025
How to fix a Franke F3D3P drum that is not rotating?
- G
  georgeguzmanSep 7, 2025
  If the Dispenser drum is not rotating, it could be due to several reasons: * The load chute might be full, the drum rotates only when the load chute is empty. * The hopper might be empty, look for a 'Low Product' warning and flashing 'Reset' lights. If so, fill the hopper with fries and push the 'Reset' button. * Fries may have formed a bridge, shake the hopper gently to redistribute the fries and break up the bridge.
M
Micheal SchultzSep 8, 2025
What does 'Low Product' message mean on my Franke Dispenser?
- A
  Angela BrooksSep 8, 2025
  The 'Low Product' message on your Franke Dispenser indicates that the hopper is running low on fries or frozen fries in the hopper have formed a void around the sensor. To resolve this, fill the hopper with fries or shake the hopper to redistribute the fries and break up any void. After that, press the 'Reset' button to restart the drum and begin the fill cycle.
S
Stephen JohnsonSep 2, 2025
Why is the basket symbol not lit on Franke F3D3P?
- J
  John HudsonSep 2, 2025
  If the basket symbol on your Franke Dispenser isn't lighting up, it means the dispenser lane is switched off. Press the ON/OFF button for 4 seconds until the button LEDs light up.
K
Krista DudleyAug 31, 2025
Why won't the freezer door close on my Franke Dispenser?
- R
  Robert OsborneAug 31, 2025
  If the freezer door on your Franke Dispenser isn't closing properly, it might be because the hopper(s) is/are not correctly engaged in the drum hub. Press the hopper into the appliance, turning the drum at the handle if necessary.

Franke F3D3P Specifications

General

Model	F3D3P
Brand	Franke
Material	Stainless Steel
Capacity	3 liters
Installation	Countertop
Voltage	220-240 V
Power Supply	Electric
Type	Dispenser

Summary

Service Operation and Maintenance

Model Identification Guide

Guide to identifying different F3D3 models based on features.

Troubleshooting and Error Messages

Guide to diagnosing issues and understanding error codes.

Setup and Programming Instructions

Procedures for accessing and modifying unit settings.

Parts Replacement

General Service Instructions

Essential instructions, warnings, and tools for service.

Freezer Door Gasket Replacement

Step-by-step guide for replacing the freezer door gasket.

Automation Assembly Replacement

Procedure for replacing the automation assembly.

Drum Rotor Motor Replacement

Steps to replace the drum rotor motor.

Component Adjustments

Low Product Sensor Adjustment

Adjusting the sensitivity of the low product sensor.

Reverse Door Hinges/Door Swing

Instructions for reversing door hinges and swing direction.

Refrigeration System Service

Propane System Service Restrictions

Critical restrictions and warnings for servicing propane models.

Basic Refrigeration Maintenance

Routine maintenance procedures for the refrigeration system.

Condenser Fan Motor Replacement

Procedure for replacing the condenser fan motor.

Factory Level Setup

Factory Level 1 Setup Access

Instructions for accessing factory-level 1 setup parameters.

Factory Level 3 Parameter Access

Guide to accessing and modifying factory-level 3 parameters.

Warranty Information

Franke New Equipment Limited Warranty

Details the limited warranty coverage for new equipment.

Franke Service Commitment

Service Contact Information

Contact details for Franke technical support and service network.

Troubleshooting Procedures

Troubleshooting Questions

Step-by-step questions to diagnose service issues.

Error Messages and Actions

Lists common error messages and required actions.

Parts List and Diagrams

Access Panels, Filter & Casters

Lists parts for access panels, filters, and casters.

Freezer & Dispensing Components

Lists loose component parts for freezer and dispensing.

Control Panel & Master Board Parts

Lists parts for control panel and master board.

Electrical Components

Lists electrical components mounted on DIN rail.

Load Cell Assembly Parts

Lists parts for the load cell assembly.

Electric Schematics

120-Volt Wiring Diagram

Wiring diagram for 120-volt operation.

230-Volt Wiring Diagram

Wiring diagram for 230-volt operation.

Control Panel Operations

Control Panel Quick-Guide

Quick guide to control panel functions and components.

Customer Level Programming

Customer Level Access

Procedures for accessing customer-level settings and parameters.

Load Cell Calibration

Load Cell Calibration Procedure

Step-by-step procedure for calibrating the load cell.

Field Service Instructions

Introduction to Field Service

Basic introduction to field service for F3D3 series.

Suggested Repair Parts

Recommended parts for ensuring first-trip fixes.

Parts Replacement Procedures

Load Cell Replacement

Step-by-step guide for replacing the load cell.

Door-Closing Spring Replacement

Procedure for replacing the door-closing spring.

Automation Assembly Replacement

Procedure for replacing the automation assembly.

Main Control Board Replacement

Steps for replacing the main control board.

Power Cord Replacement

Procedure for replacing the power cord.

Component Adjustments

Low Product Sensor Adjustment

Adjusting the sensitivity of the low product sensor.

Reverse Door Hinges/Door Swing

Instructions for reversing door hinges and swing direction.

Automation Assembly Alignment

Aligning the automation assembly for proper fit.

Fry Hopper Hanger Alignment

Aligning the fry hopper for proper installation.

Control Board Configuration

Backup Temperature Display Setup

Reconfiguring control board for backup temperature display.

Refrigeration System Service

Propane System Service Restrictions

Critical restrictions and warnings for servicing propane models.

Basic Refrigeration Maintenance

Routine maintenance procedures for the refrigeration system.

Condenser Fan Motor Replacement

Procedure for replacing the condenser fan motor.

Refrigerant Pressure & Leak Detection

Guide to checking refrigerant pressure and detecting leaks.

Condensing Unit Replacement

Steps to replace the condensing unit.
