Franke F3D3 Service Manual

F3D3 Series Service Manual Parts Replacement / Section 2.18
Questions? Call Franke Technical Support Group For Your Area. Copyright  2012 Franke, Inc. All rights reserved.
2.18 24-Volt Power Supply Replacement
Continued…
19) A small green LED will light on the power supply,
indicating it is functioning properly. [You will also hear
the compressor come on to begin freezer compartment
chilling.]
20) Return Dispenser to normal operating position and lock
front casters.
[Photo 5
]
Use a flat blade screwdriver to
depress the tab below the power
supply bottom, to release it from
the DIN mounting rail.
Rev. 1 6/2012

Tools Required:
 Medium Phillips screwdriver
 2-3 mm [1/8”] flat blade screwdriver
 6-7 mm [1/4”] flat blade screwdriver
