Franke F3D3P User Manual

16
07/2 0 15
F3D3S und F3D3SP–Single Lane
Frozen fry dispenser F3D3S/F3D3/ F3D3SP/F3D3P
en
Warning and pro-
hibitory signs
Storage area for
unused baskets
Castors without brake
Castors with brake
Lower drip pan (plastic)
Lower basket wire rack
Upper basket wire rack with basket guide
Freezer bottom
Handles for manually turning the drum
Deflector (rubber)
Hopper with
drum
Control panel of the
dispenser lane
Access plates to condenser
F3D3SP Type label
Compressor cabinet
Power switch
F3D3S type label behind
the air filter
Crumb Tray (option)
